??1, rubber mould preview:

??In injection molding machine, rubber mold mount should be tested, so as to find quality problems in a timely manner, to repair the mold to avoid computer and then removed, when mold fixed template and mobile template separate checks, pay attention to the direction, to avoid make a mistake when clamping.

??2, more is the peak of the distance:

??Rubber mold after fastening, rev die slowly, until the dynamic template to stop back, this is the position of the plunger should be adjusted to the mold ejection plate and the dynamic model of the plate was left not less than 5 mm clearance between to prevent damage to the mold, and hold out the parts.

??3, mold closing firmness to adjust:

??To prevent overflow, and ensure that appropriate cavity exhaust, in regulating hydraulic ram - toggle clamping mechanism, mainly by visual and experience, in the closed modules, namely toggle quickly before they are slow, that is not naturally, also not too reluctantly unbend, mold closing looseness is just the right. Rubber mold, for mould temperature should be tried in the mold after ascension mould temperature, then the school closed die firmness.

??4, cooling water:

??After turn on the cooling water, should check whether the open and leaking.

??5, oblique guide mould installation:

??Loading mode, the two people should closely pay attention to safety, if have a side parting mechanism of mold, slides should be installed in a horizontal position, namely active blocks are moving around.

??6, rubber mold clamp:

??When the mold in injection molding machine template of position locating circle after, with extremely slow speed closed modules, makes dynamic templates will die compaction gently, and then the pressure plate, pressure plate must be fitted with gasket, pressure must be up and down the 4 boards, pressure plate, must pay attention to adjust the height of the screw will be dispatched to with mold feet high, the pressure plate to be flat. If the pressure plate is inclined, cannot the rubber mold of foot pressure is very tight. Keep plate profile is close to the mold, rubber mold in order to avoid friction damage.
